Acer Aspire Switch 10E SW3-013 How to do a clean install from a USB disk drive

Hi everybody,

My notebook at boot cant find the boot device. I what to perform a new installation of the windows 10 32 Bit from a bootable USB Pen. But the machine does not allow me to install from the OTG or from the USB slot from the dock. I start the installation and when I reach the stage of choosing the installation partition I receive the following message:

"Windows cannot be installed to this disk. Setup does not support configuration of installation to disks connected trough a USB or IEE 1394 port."

what can I do to reinstall windows?

Thanks

Accepted answers

Commodore_1995#

As I told you before, you can install the microsoft iso. To do this, simply delete the emmc partitions and install windows again. The problem is that this procedure will erase erecovery, which for some reason has been damaged.

All comments

Commodore_1995#

Have you converted the flash drive to gpt and graduated to fat32? Also, have you downloaded an x86 iso and disabled secureboot?

ZeTo

OI, muito obrigado pela pronta atenção.

Thank you for your response.

I´ve downloaded from Microsoft official repository the latest windows 10 32 Bits as an ISO file. Then I used RUFUS to create a bootable Flash drive. But as I boot from that drive I cant manage to install to my Internal Drive. I suppose that is a kind of solid drive or a solid memory. When I turn on my device it shows a message saying that "No Boot Device foud"

ZeTo

Is it possible to communicate in Portuguese?

Commodore_1995#

Check this links:
https://community.acer.com/en/discussion/499644/i-cant-make-a-clean-windows-10-installation-in-my-acer-aspire-switch-10e-sw3-016
https://www.microsoft.com/en-us/software-download/windows10startfresh

ZeTo

I've the BIOS configuration properly done, I thing. The Tablet boots from the Pen drive and start the installation procedure. I choose the Language, Date format and Keyboard Layout. Then, the Partition shows up to install but the program says immediately that windows can not be installed in the drive. This is the message:

"Windows cannot be installed to this disk. Setup does not support configuration of installation to disks connected trough a USB or IEE 1394 port"

If I press F10 to open the Command prompt, the screen turns black and the tablet froze...

Commodore_1995#

Have you tried reinstalling windows by just pressing alt + f10 before the Acer logo?

ZeTo

If ALT + F10 pressed prior to the ACER logo this message shows up:

" Default boot Device Missing or Boot Failed. Insert Recovery Media and Hit any Key Then select "Boot Manager to choose a new Boot Device or to Boot Recovery Media."

I´ve pressed the Alt+F10 Keys without the windows 10 bootable pen drive inserted.

I DONT HAVE A RECOVERY MEDIA

Commodore_1995#

You can try a hard reset like this:

https://youtu.be/fymuPFClID0

ZeTo

I can't boot normally in windows. That is the problem. My Tablet does not open at all. Only in a kind of Safe mode from ACER that only allow me to configure boot options.

Commodore_1995#

Can you send a screenshot of these options that appear?

ZeTo

I finally get the command prompt and tried to Convert the installation partition to GPT and it was not possible as you can see from the photos

Image: https://us.v-cdn.net/6029997/uploads/editor/qx/4d2bkjs8by3h.jpg

.

ZeTo

Those are the option

Image: https://us.v-cdn.net/6029997/uploads/editor/ul/bkxzsv1embdt.jpg

Image: https://us.v-cdn.net/6029997/uploads/editor/9x/4daixlu29hw8.jpg

s that

Image: https://us.v-cdn.net/6029997/uploads/editor/cp/ynrkayxojn8f.jpg

I've when I power on the Tablet.

ZeTo

And also it is how I've configured the boot sequence

ZeTo

Windows boot partition does not exist.

ZeTo

I need to kind off FLASH my system.

Commodore_1995#

Try installing this driver here: https://global-download.acer.com/GDFiles/Driver/Platform Drivers/Platform Drivers_Acer_1.10_W81x86W10x86_A.zip?acerid=636240283149867083&Step1=NOTEBOOK&Step2=ASPIRE SWITCH&Step3=SW3-013&OS=10M2&LC=pt&BC=ACER&SC=PA_3#_ga=2.23343485.63398170.1578509488-29169035.1578509488

Image: https://us.v-cdn.net/6029997/uploads/editor/kc/0yobduf66cee.png

Image: https://us.v-cdn.net/6029997/uploads/editor/5r/cg9mjbzmjco1.jpg

ZeTo

I've downloaded the zip file already. How do I install the driver? Copy the zipped file to the bootable win10 pen drive?

Commodore_1995#

You can extract to the flash drive that contains windows 10, but put the file in a different folder! Or you use another USB stick.

ZeTo

Ok, I've extracted the zipped files to a new folder in the Bootable Windows Pen Drive. Never did that before during a windows installation... What drivers must I install? All?
