Request for motherboard dimensions – Acer JM50 Main Board Rev 3.1 (Aspire M5-581T)

Options
cepe_s
cepe_s Member Posts: 1 New User

I'm working on building a custom metal chassis for my Acer Aspire M5-581T and need the exact dimensions and mounting hole positions of the JM50 main board Rev 3.1. I’m especially interested in:

  • Total length and width of the board
  • Positions and diameters of the screw holes
  • Locations of external ports (USB, HDMI, power, etc.)

Any official schematics, drawings, or measured data would be greatly appreciated.

Thanks in advance!
