Swift 3 314-56g thermal pads thickness

hivonzoooo
hivonzoooo Member Posts: 14

Tinkerer
edited February 2021 in Swift and Spin Series
I want to dissasembly my laptop for SSD and RAM upgrade i am thinking about changing the thermal paste too. But in this video, when he is removing the heatsink, there are two thermal pads beneath it. Where i can find a information how thick they are? I have two packs of Thermal Grizzly Minus Pads, first one that contais 1mm pads and second with 2mm, but I don't know if they will fit. Model number of my Swift 3 is NU-SF314-56G-58J0.






Best Answer

  • hivonzoooo
    hivonzoooo Member Posts: 14

    Tinkerer
    Answer ✓
    I can confirm now that thermal pads are 1mm thick.

Answers

  • Tachi13
    Tachi13 Member Posts: 135 Skilled Fixer WiFi Icon
    Hi @hivonzoooo

    Using a thermal pad is as same as using a thermal paste, I recommend you to use thermal paste, but if you want to use thermal pad, you have to use the 1mm thickness, on the other side, higher thickness allows it to absorb more deformations in the chip/heatsink surface, but it is worse in terms of heat transfer. Yes, thicker is worse in terms of heat transfer. Doubling the pad thickness doubles the thermal resistance, you don't want resistance, you want conduction. When it comes to the thickness, it doesn't make any difference it fitting the heatsink and the component.

    Please click on "Yes" if you find this answer helpful. :):)
    Please click on "Yes" if you find this answer helpful. :):)
  • hivonzoooo
    hivonzoooo Member Posts: 14

    Tinkerer
    Tachi13 said:
    Hi @hivonzoooo

    Using a thermal pad is as same as using a thermal paste, I recommend you to use thermal paste, but if you want to use thermal pad, you have to use the 1mm thickness, on the other side, higher thickness allows it to absorb more deformations in the chip/heatsink surface, but it is worse in terms of heat transfer. Yes, thicker is worse in terms of heat transfer. Doubling the pad thickness doubles the thermal resistance, you don't want resistance, you want conduction. When it comes to the thickness, it doesn't make any difference it fitting the heatsink and the component.

    Please click on "Yes" if you find this answer helpful. :):)
    I knows the difference between thermal paste and thermal pads. In the video that i have attached you can clearly see two thermal pads near the fan. They have nothing to do with CPU and GPU as they are located at the end od the heatsink. I just wants to know how thick they are to replace them with better ones.
  • billsey
    billsey ACE Posts: 33,937 Trailblazer
    The Service Guide just says: "Make sure all thermal pads for the mainboard chipsets and VRAMs are in place before replacing the thermal module." The FRU list doesn't have the pads listed, so I can't find info with their thickness. You might be able to measure the thickness when you get it apart, but that's a little late in the process to be ordering the replacements.
    Click on "Like" if you find my answer useful or click on "Yes" if it answers your question.
  • hivonzoooo
    hivonzoooo Member Posts: 14

    Tinkerer
    billsey said:
    The Service Guide just says: "Make sure all thermal pads for the mainboard chipsets and VRAMs are in place before replacing the thermal module." The FRU list doesn't have the pads listed, so I can't find info with their thickness. You might be able to measure the thickness when you get it apart, but that's a little late in the process to be ordering the replacements.

    Right now i have Thermal Grizzly Kryonaut and Thermal Grizzly Minus Pads 1mm and 2mm, lets hope one of them will fit.
  • billsey
    billsey ACE Posts: 33,937 Trailblazer
    Very likely they will, please let us know what you see.
    Click on "Like" if you find my answer useful or click on "Yes" if it answers your question.
  • hivonzoooo
    hivonzoooo Member Posts: 14

    Tinkerer
    billsey said:
    Very likely they will, please let us know what you see.

    I will, i just need to wait few days to complete everything.
  • hivonzoooo
    hivonzoooo Member Posts: 14

    Tinkerer
    Answer ✓
    I can confirm now that thermal pads are 1mm thick.
  • billsey
    billsey ACE Posts: 33,937 Trailblazer
    Great! That should be a big help to the next user who needs to do this.
    Click on "Like" if you find my answer useful or click on "Yes" if it answers your question.
