Aspire VX5-591G Wont Power On

jeffrimko
jeffrimko Member Posts: 12

Tinkerer

edited November 2023 in 2020 Archives
Laptop suddenly will no longer power on. Plugging in the power supply does nothing, no LED lights up. Things I've tried:
  1. Checked that the power supply works with a voltmeter, it is outputting 19V correctly.
  2. Resetting the battery using the small pinhole in the case.
  3. Removing the bottom cover and disconnected the main battery and the CMOS battery for a while.
  4. Checked that 19V from the power supply is reaching the connector on the motherboard.
  5. Used a bench power supply to apply 19V to where the power would normally come in, no current is being drawn from the supply at all (or at least it is less than 0.5 mA).
  6. Removed the memory, M.2 drive, and WiFi module to eliminate possibilities they might be bad, still nothing.
Has anyone run into similar issues? Guessing there might be a bad component on the motherboard somewhere.

Answers

  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Forgot to mention that I've also checked that the case removal switch works using a multimeter in beep mode. Have it temporarily taped down while working on it. Had issues previously with this switch where the laptop would suddenly shut off at random because the case screws loosened over time.
  • Forgot to mention that I've also checked that the case removal switch works using a multimeter in beep mode. Have it temporarily taped down while working on it

    Did you check these two buttons?

    Oi! Eu não sou sou a cortana! Mas estou aqui para ajudar! Hi! I'm not the cortana! But I'm here to help!
    Se você gostou da minha resposta, marque como solução clicando em sim! If you liked my answer, mark it as a solution by clicking on yes!
    Aceite somente a resposta que ajudou a solucionar o seu problema! Please accept only the response that helped to solve your problem!
    Detection tool click here to find the serial number or partnumber of your model!

                                                     egydiocoelho Trailblazer

    ProductKey clique aqui para descobrir o serial do windows! click here to discover the windows serial!
    Para usuários da comunidade inglesa, espanhola, francesa e alemã, usarei o google tradutor! :)
    For users of the English, Spanish, French and German community, I will be using google translator! :)
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Thanks for the quick response! Yeah, I just checked both with a multimeter. They both appear to be working properly. They both connect to ground when pressed which I'm guessing is correct.
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Think the rightmost switch in the picture is the case removal switch (the one just below the memory). That's the one I have taped down. Unless there is another switch somewhere that detects if the case is removed.
  • There are two buttons, see:

    In some versions, there is still the battery reset button:

    Oi! Eu não sou sou a cortana! Mas estou aqui para ajudar! Hi! I'm not the cortana! But I'm here to help!
    Se você gostou da minha resposta, marque como solução clicando em sim! If you liked my answer, mark it as a solution by clicking on yes!
    Aceite somente a resposta que ajudou a solucionar o seu problema! Please accept only the response that helped to solve your problem!
    Detection tool click here to find the serial number or partnumber of your model!

                                                     egydiocoelho Trailblazer

    ProductKey clique aqui para descobrir o serial do windows! click here to discover the windows serial!
    Para usuários da comunidade inglesa, espanhola, francesa e alemã, usarei o google tradutor! :)
    For users of the English, Spanish, French and German community, I will be using google translator! :)
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Ah okay, just checked and the model I have does not have that extra switch. I see the empty footprint where it would be placed though. Here's a picture of the motherboard, a lot of stuff is disconnected while I investigate and I removed the tape from the SW2 switch:


  • Did the same problem occur when disconnecting the lithium battery and have you tested it with another ram? Do the battery and power LEDs light or flash?
    Oi! Eu não sou sou a cortana! Mas estou aqui para ajudar! Hi! I'm not the cortana! But I'm here to help!
    Se você gostou da minha resposta, marque como solução clicando em sim! If you liked my answer, mark it as a solution by clicking on yes!
    Aceite somente a resposta que ajudou a solucionar o seu problema! Please accept only the response that helped to solve your problem!
    Detection tool click here to find the serial number or partnumber of your model!

                                                     egydiocoelho Trailblazer

    ProductKey clique aqui para descobrir o serial do windows! click here to discover the windows serial!
    Para usuários da comunidade inglesa, espanhola, francesa e alemã, usarei o google tradutor! :)
    For users of the English, Spanish, French and German community, I will be using google translator! :)
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Tried leaving the battery disconnected then connected the power supply but no LEDs turn on and the power button is unresponsive. Unfortunately I don't have any other RAM to test with. Guessing they are not the issue though since the LEDs would likely still come on even if the RAM is removed. Guessing something is up with the power circuitry on the motherboard somewhere, maybe a bad MOSFET?

    I checked the voltage of the CMOS battery also. It's 2.8V which is pretty close to the 3.0V it's supposed to be.
  • I found a video in German, in which the problem is very similar, see:
    Of course, the problem may also be elsewhere on the motherboard.
    Oi! Eu não sou sou a cortana! Mas estou aqui para ajudar! Hi! I'm not the cortana! But I'm here to help!
    Se você gostou da minha resposta, marque como solução clicando em sim! If you liked my answer, mark it as a solution by clicking on yes!
    Aceite somente a resposta que ajudou a solucionar o seu problema! Please accept only the response that helped to solve your problem!
    Detection tool click here to find the serial number or partnumber of your model!

                                                     egydiocoelho Trailblazer

    ProductKey clique aqui para descobrir o serial do windows! click here to discover the windows serial!
    Para usuários da comunidade inglesa, espanhola, francesa e alemã, usarei o google tradutor! :)
    For users of the English, Spanish, French and German community, I will be using google translator! :)
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Thank you very much for finding that video! It's useful to see how to remove the motherboard, I haven't tried removing it yet because wasn't sure if the heatsinks also had to be removed. I will take a closer look later today to see if I can find a damaged component.
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    edited August 2020
    Haven't found a visibly damaged capacitor yet like in the video. Checked a few MOSFETs and found one that might be an issue, it has 19V on the drain and 0.2V on the source and gate. Checked this with the CMOS battery installed to make sure that didn't factor into the MOSFET turning on. The designator is PQ302, haven't tried putting a jumper around it yet.


  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Was able to find a schematic for this motherboard. After reviewing it a bit, don't think that previously mentioned MOSFET is the issue. Going to debug a bit more later today. Will report back if I find anything.
  • Have you encountered the problem?
    Oi! Eu não sou sou a cortana! Mas estou aqui para ajudar! Hi! I'm not the cortana! But I'm here to help!
    Se você gostou da minha resposta, marque como solução clicando em sim! If you liked my answer, mark it as a solution by clicking on yes!
    Aceite somente a resposta que ajudou a solucionar o seu problema! Please accept only the response that helped to solve your problem!
    Detection tool click here to find the serial number or partnumber of your model!

                                                     egydiocoelho Trailblazer

    ProductKey clique aqui para descobrir o serial do windows! click here to discover the windows serial!
    Para usuários da comunidade inglesa, espanhola, francesa e alemã, usarei o google tradutor! :)
    For users of the English, Spanish, French and German community, I will be using google translator! :)
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Haven't found the problem yet. Been using a multimeter in beep mode and checking around the motherboard for shorts to GND. There are a lot. Focusing only on the large inductors, there are seven that are shorted to GND: PL809, PL807, PL806, PL7201, PL1301, PL602, PL402. Unfortunately, I don't have good soldering equipment on hand to try and remove some of the inductors to isolate where the short is coming from. Still thinking about what to do next.
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Thinking about it more, it's strange that with so many shorts to GND that there doesn't appear to be any current drawn from the bench power supply. I even tried ramping up the voltage but never seen any current draw register. Maybe there is short circuit protection somewhere that is active. I will try tracing from the power supply jack more carefully to see if I can find anything.
  • Perhaps the motherboard wiring diagram can help you.
    I found this video:
    Oi! Eu não sou sou a cortana! Mas estou aqui para ajudar! Hi! I'm not the cortana! But I'm here to help!
    Se você gostou da minha resposta, marque como solução clicando em sim! If you liked my answer, mark it as a solution by clicking on yes!
    Aceite somente a resposta que ajudou a solucionar o seu problema! Please accept only the response that helped to solve your problem!
    Detection tool click here to find the serial number or partnumber of your model!

                                                     egydiocoelho Trailblazer

    ProductKey clique aqui para descobrir o serial do windows! click here to discover the windows serial!
    Para usuários da comunidade inglesa, espanhola, francesa e alemã, usarei o google tradutor! :)
    For users of the English, Spanish, French and German community, I will be using google translator! :)
  • jeffrimko
    jeffrimko Member Posts: 12

    Tinkerer

    Update on this, I think the Skylake PCH chip may have failed. This is based on:
    1. A number of shorted power supply lines run directly to the PCH, e.g. +1.0VALW.
    2. When supplying 1V to one of these shorted power supply lines and limiting the current to a few amps, the PCH is the only component that seems to get warm.
    So unless the PCH pulls a bunch of power lines to ground when its not powered on, the chip appears to be the issue. If it does pull a bunch of lines to ground, it makes debugging a nightmare. Either way, I likely will not attempt any further repair and will probably try to sell it for parts. Thanks again for the help!
